Watson Stainless Steel 25 FA Back Connection Pressure Gauge
The Watson-Atlantis PG-25FA is a 25 Bar (350 PSI) Flange Pressure Gauge in a stainless steel (AISI 316) body and has a G 1/4" BSPT thread at the back. This stainless steel gauge is an incredible a value proposition in that no other stainless steel gauge is offered at the same price point. This gauge is designed to be panel mounted.
The polycarbonate dial surface allow for high readibility with a sharp black pointer. Dial has dual scales in PSI and BAR. The Dial Size is 63mm (2.5").
The Watson PG-25FA is also offered as a Gylcerin-filled variant which has anti-vibrational and anti-corrision properties.
(Pictures are for reference only. Units may not be to scale).
Made in Taiwan.
Technical Specifications of Watson PG-25FA Pressure Gauge
| Dial Size | 63mm (2.5") |
| Material Composition | Stainless Steel 316 Chasis |
| Thread Entry Position | Back Entry |
| Thread Size and Type | G 1/4" BSP |
| Dial Units | PSI and Bar |
| Operating Temperature | -20 - +60 Celcius |
| Overrange Protection | 120% of Full Scale |
