Mindman MCHG2-80M Pneumatic Gripper (Three Finger)
This is the MCHG2-80M pneumatic gripper from Mindman. Three finger gripper with piston diameter of 80mm
Replacement of the old MCHG series
Mounting holes on body
Full Specifications
| Acting type | Double acting |
| Fluid | Air |
| Operating pressure range | 0.1~0.6 MPa |
| Ambient temperature | －10~＋60℃ (No freezing) |
| Max.operating frequency | 30~120 (c.p.m) |
| Lubrication | Not required |
| Effective force (N.m) at (0.5 MPa) | Extemal: 14N~1270N, Internal: 16N~1320N (※1) |
| Sensor switch | 2 wire: RDFE(V): Non-contact |
| 3 wire: RNFE(V): NPN, RPFE(V): PNP |
