Univer M100 Ø20/50 Pneumatic Cylinder
UINVER
M100 Ø20/50
M-series ISO 6432 Microcylinders
1=Stainless steel piston rod (Standard vesion)
00=D.A Standard Version
020=Bore (mm)
0050=Stroke (mm)
Technical Specifications
| Ambient temperature | -20÷80℃ |
| Fluid | filtered air, with or without lubrication |
| Working Pressure | 1,5÷10 bar |
| End-caps | aluminium, crimped on barrel |
| Barrel | stainless steel |
| Piston | brass(Ø8÷16), aluminium (Ø20÷25) |
| Guide slide | acetalic resin |
| Piston rod | stainless steel |
| Piston seals | NBR |
| Guide bush for piston rod | standard supplied |
| Shock absorber seals | NBR |
| Cushionings | pneumatic adjustable (Ø16÷25) |
