Knocks G63 1/4" 25 bar Pressure Gauge
KNOCKS
MPN 9.3700.00.244
Made in Germany
Technical Specifications
| Port size | G 1/4 |
| Description | Bourdon tube pressure gauge (EN 837-1) |
| Accureacy class | 2,5 (EN 837-1/6) |
| Mounting | Arbitary |
| Case | Black plastic |
| Window | Crystal-clear plastic, snap-fit |
| Scale ranges | EN 837-1/5 0 to 25 bar |
| Working pressure, steady | 0 to 18,5 bar |
| Working pressure, fluctuating | 0 to 16,5 bar |
| Media and ambient temperature | 0℃ to 60℃ |
| Temperature effect | When temperature of the pressure element deviates from reference temperature (+20℃ ): Max.±4% / 10℃ of the span |
