Univer CL-110A Ball-Push Mechanical Spool Valve 1/8"
UNIVER CL-110A Ball Push Mechanical Valve
Valves G1/8-G1/4 with indirect mechanical operation for pneumatic and mechanical operators
Ball push
CL-110A G1/8
Technical Specifications
Ambient temperature | -10÷45℃ |
Fluid | 50 μm filtered air, with or without lubrication |
Commutation system | Spool |
Valve Body | die-cast zamak (G 1/8), aluminium (G 1/4) |
Seals | Nitrile rubber |
Spool | Aluminium |
Electropilot / Coil | AA Series / U1-U3 |
Power Consumption | 3,5 W (DC)-5 VA (AC) |
Connector | AM5110 |
Voltage | 12VDC-24VDC-24VAC-110VAC-230VAC |
Manual Override | Two-position screw |
Connections | G 1/8 | G 1/4 |
Nominal bore (mm) | 6,5 | 8,5 |
Nominal flow rate (Nl/min) | 890 | 1480 |
